Parameters

• Fingerprint Capacity

  5,000

• Face Capacity

  3,000 (1:N) / 4,000 (1:1)

• Cards (Optional) Capacity

  10,000

• Transaction Capacity

  100,000

• Communication

  TCP / IP / USB Host / Wiegand Output

• Access Control Interface

  Lock Relay Output / Alarm Output / Exit Button / Door Sensor / External Bell

• Hardware

  4.3 inch Touch LCD / 1.2GHz High Speed CPU / Memory 128MB RAM / 256MB Flash / SilkID Fingerprint Sensor / 168 Infrared Sensors

• Standard Function

  ID Card / Work Code / ADMS / DST / SMS / Schedule Bell / Automatic Status Switch / Record Query / Photo ID / Custom Wallpaper & Screen Saver

• Special Function

  Precise facial recognition under strong sunlight (up to 60,000 Lux) / Latest ZKTeco Facial Recognition Algorithm, easy to recognize users wearing glasses and hat / Prevents repeated face registration

• Optional Function

  HID Proxy / IC Card / Wi-Fi / 3G / External Printer / Battery (2,000 mAH) / PoE (Standard IEEE 802.3at)

• Compatibility

  ZKTime.Net 3.0 / ZKBio Time

• Operating Temperature

  0 °C ~ 45 °C

• Dimension

  199.2 × 171.8 × 131.3 mm

• Algorithms

  ZKFace v9.0 & ZKFinger v10.0

• Fingerprint

  FAR≤ 0.0001% FRR≤ 0.01%

• Face

  FAR≤ 0.001% FRR≤ 1%

• Operating Voltage

  12V DC

• Current Draw

  < 500 mA
