Parameters

• Fingerprint Capacity

  20,000

• Card Capacity

  20,000

• Transaction Capacity

  200,000

• Communication

  TCP/IP
  USB Host
  Wiegand Input / Output

• Access Control Interface

  Lock Relay Output
  Alarm Output
  Exit Button
  Door Sensor
  External Bell Output

• Hardware

  1.2GHz High Speed CPU
  Memory 128MB RAM / 256MB Flash
  Z-ID Fingerprint Sensor
  3.5 Inches TFT-LCD Screen
  Hi-Fi Voice & Indicator
  Tamper Switch Alarm

• Standard Function

  ID Card / Work Code / ADMS
  DST / SMS / Schedule Bell
  Automatic Status Switch
  Query / Photo ID
  Anti-Passback
  Custom Wallpaper & Screen Saver

• Optional Function

  HID Proxy / IC Card External Printer
  Wi-Fi / 3G

• Special Function

  Multiple Verification Modes
  Alive Finger Detection

• Compatibility

  ZKBio Time
  ZKTime.Net 3.0

• Additional Info

  Working Temperature: 0 °C ~ 45 °C
  Dimensions: 206.0 × 153.0 × 42.9 mm
  Fingerprint Algorithm ZKFinger v10.0
  FAR≤0.0001% FRR≤0.01%

• Power

  Operating Voltage 12V DC
  Current Draw < 500 mA
